Playground System GFP-3004

Large-scale commercial playground system designed for ages 5 to 12, featuring multiple elevated play zones, high-capacity circulation paths, and a wide range of climbing, sliding, and interactive elements for continuous engagement.

Specifications

Model Number: GFP-3004

Age Group: 5–12 Years

User Capacity: 75–80 Children

Structure Size: 38' x 52'

Use Zone: 50' x 64'

Surface Area: 2,071 sq ft

Fall Height: 7 Feet

Estimated Timber Count: 53

Elevated Play Activities: 15

Ground-Level Accessible Activities: 5 Required / 5 Provided

Ground-Level Accessible Activity Types: 3 Required / 4 Provided

Play Components

Open Spiral Slide

Alpine Thunder Slide

Chute Slide

Straight Crawl Tunnel

Talk Tube

Vertical Ladder

Pipe Ladder

Pipe Wall

Totem Climber

Inclined Ramp with Rocks Climber

Bilateral Climber

Rock Wall Climber

Clatter Bridge

Arch Bridge

Bubble Ladder

Loop Rung Horizontal Ladder

Trapeze Ring Horizontal Ladder

90 Degree Tri Rung Horizontal Ladder

Track Ride

Post Mount Steering Wheel

Cafe Market Panel

Bench Below

Single Step with Grab Handles

48" Transition Stair Unit

10' x 10' Shade Structures

Design Overview

This playground system is designed as a multi-zone structure with interconnected elevated decks that support high user capacity and continuous circulation. The layout distributes activities across a broad footprint to reduce congestion and maintain active flow throughout the play environment.

Multiple slide types are strategically positioned to balance user movement. The Alpine Thunder slide provides a tall, enclosed descent, while the open spiral and chute slides create varied exit paths that keep users engaged and moving across the structure.

Climbing elements are extensive and layered to support progressive difficulty. Features such as the rock wall, bilateral climber, totem climber, and inclined ramp offer vertical and angled challenges, while horizontal ladders and track ride elements promote upper body strength and coordination.

Bridges, tunnels, and transition elements connect the structure and enhance exploration. The arch bridge, crawl tunnel, and clatter bridge create varied pathways that encourage users to move between zones while maintaining visual and physical engagement.

Interactive and sensory play is incorporated through panels, talk tubes, and activity stations. These features support imaginative play, communication, and group interaction, increasing dwell time and overall play value.

Accessibility

This structure meets ground-level accessibility requirements by providing all required accessible play activities and exceeding minimum activity type counts. Ground-level components are positioned to allow inclusive participation without requiring elevated access.

Safety Considerations

The maximum fall height of 7 feet requires compliant impact attenuating surfacing throughout the use zone. The 50 foot by 64 foot use zone must remain clear to maintain proper spacing and safe circulation between all components.

Applications

Ideal for large parks, schools, and high-traffic community playgrounds requiring a high-capacity system. This structure is designed to handle large user volumes while providing a wide range of play experiences for children ages 5 to 12.

Summary

The GFP-3004 playground system is a high-capacity commercial play structure designed for children ages 5 to 12, supporting up to 80 users within a 50-foot by 64-foot use zone. With multiple slides, extensive climbing systems, bridges, tunnels, and interactive features, this system delivers a diverse, durable, and highly engaging play environment suited for large-scale installations.
